Features
1. Z-Wave Plus 500 Series protocol
2. Offers univirsal compatibility, working with or without a neutral wire
3. Automatically detects lighting type for smooth dimming
4. Z-Wave SmartStart
5. Compatible with LK Fuga Frame
6. With an extra terminal for push switch to offer multiway switch on/off and dimming
7. Simply replaces existing wall dimmer
8. Requires in-wall installation with hard-wired connections
Supported loads with on/off/dimming
Incandescent
Dimmable LED
Halogen with or without electronic transformer
Compatible App
Fibaro Home Center Lite / 2 / 3
Amazon Echo Plus
SmartThings
Wink
Vera
Homey
DATA SHEET
- Model Number: D081E2-ZV
- Power Supply: 220-240V, 50Hz
- Min. Load: 8W (Without bypss)
3W (Bypass required)
- Max. Load:
Dimmable LEDs up to 200W
Incandescent up to 300W
Halogen up to 300W
- Dimming Technology: Trailing edge / phase / R,C
- Control Way: One way / Multiway (Only activate when the P port is connected to push switches)
- Connection terminal: Screw-in terminal, max 2.5mm2
- Connections: 2 x Line (looped internally)
1 x Neutral input
1 x Push switches (For multiway dimming and on/off)
- Radio protocol: Z-Wave Plus 500 (EU 858.4MHz)
- Dimension: 45.0*45.0*40.45mm
- Weight: 35g (Without Coverplate)
DIMENSION
To know further details of this product, please download the following user manual.
